| Product Name |
Fiber Optic Patch cord |
Fiber Model |
Multimode |
| Product Model |
FC/UPC-LC/UPC MM OM1 DX |
Fiber Core |
62.5/125μm |
| Optical Connector |
FC-LC |
Jacket Color |
Orange |
| Connector End Face |
UPC |
Jacket Diameter |
2.0mm/3.0mm |
| Work Environment |
Indoor |
Jacket Material |
PVC/LSZH |
| Parameter |
SC, LC,FC,ST fiber patch cord |
| SM |
MM |
| PC |
UPC |
APC |
PC |
| Insertion loss(typical) |
‰¤0.3 |
‰¤0.3 |
‰¤0.3 |
‰¤0.3 |
| Return loss |
‰¥45 |
‰¥50 |
‰¥60 |
‰¥30 |
| Interchangeability |
‰¤0.2dB |
| Salt Spray |
‰¤0.1dB |
| Repeatability |
‰¤0.1dB (1000 times) |
| Vibration |
‰¤0.2dB (550Hz 1.5mm) |
| Temperature |
‰¤0.2dB (-40+85 sustain 100 hours) |
| Humidity |
‰¤0.2dB (+25+65 93 R.H.100 |
